XZM2DGxxW HRS Series - Heart Rate Sensor LEDs

Optoelectronic components have been evolving in application usages ever since its inception.  What started out as simple indicator lights for ON/OFF purposes eventually expanded to LEDs being used aesthetically, enhancing the product in ways beyond indication.  SunLED has proudly been a leading manufacturer in each of these turning points in opto technology.  Lighting the way towards the next chapter in LED evolution, SunLED introduces the HRS Series - Heart Rate Sensor LEDs.

SunLED's HRS Series is available in 0603 and 1206 packages which are ideal for any compact devices such as wearable electronics.  A variety of viewing angles are available including 30°, 60°, and 120° to provide design flexibility.  Specific wavelengths of ?P=520nm; ?D=525nm are deployed in this series, which is the key to having an accurate heart rate measurement.

Part No.Package SizeColorLensWavelengthOptical DataViewing AngleSpec3D Drawings
XZM2DG53W-11.6x0.8x0.75mm (0603)GreenWater Clear520nm400745If=20mA120°
XZM2DG53W-61.6x0.8x0.25mm (0603 Ultra Thin LED)GreenWater Clear520nm400695If=20mA120°
XZM2DG53W-81.6x0.8x0.95mm (PixsoLED)GreenWater Clear520nm7001295If=20mA60°
XZM2DG55W-13.2x1.6x0.75mm (1206)GreenWater Clear520nm400745If=20mA120°
XZM2DG55W-33.2x1.6x1.8mm (1206 Dome Lens LED)GreenWater Clear520nm31004190If=20mA35°
